Small Cam Six Shuttle Circular Loom
Performance And Characteristics:
* PLC centralized control is adopted for electric controlling, frequency speed regulation is adopted as well, which is convenient and stable.
* It is high-efficient and energy economical. The highest rotation speed of machine can reach 180r/min and the power is 2.2 KW, which can save 10 thousand degree electricity one year, compared with the original circular loom whose power is 4KW.
Main Technical Parameter:
Model | Number of shuttle | Weaving folding width | Max. number warp (pcs) | Revolutions of main motor (r/min) | Production capacity (m/min) | Power of main motor (kw) | Total power (kw) | Installing dimensions (L×W×H)(mm) | Weight (kg) |
NY-XT-850/6 | 6 | 300-850 | 720 | 120-180 | 1.8-2.7 | 2.2/3 | 2.7/3.5 | 9100×2300×2730 | 2100 |
NY-XT-1500/6 | 6 | 950-1500 | 840/1680 | 90-120 | 1.3-1.8 | 4/5.5 | 4.5/6 | 12000×2800×3200 | 3800 |
NY-XT-1700/6 | 6 | 1100-1700 | 960/1920 | 70-110 | 1.4-1.7 | 4/5.5 | 4.5/6 | 12000×3000×3600 | 44200 |
